BMS & battery packs
EASY B2
Battery management, designed in Italy.
A low-consumption Battery Management System for lithium battery applications. It monitors voltage, current and temperature and provides configurable control and diagnostic interfaces.
BUILT AROUND YOUR APPLICATION
Let's find your configuration.
Request a quotationOur team will confirm specifications, availability and pricing.
PRODUCT DETAILS
Designed for integration.
- Cell balancing and battery parameter monitoring.
- Over-voltage, over-current and over-temperature protection functions.
- CAN communication, diagnostic data and LED indications.
- On-board pre-charge and pre-discharge.
- Client-configurable parameters through the interface board.
Specifications
| Cell configuration | 10S-16S |
|---|---|
| Voltage range | 20-60 V (depending on cell chemistry) |
| Continuous current | Up to 100 A |
| Peak current | Up to 200 A |
| Operating temperature | -20 to 60 degrees C |
| Power consumption | 300 microA |
| Chemistries | Li-ion / Li-polymer / LFP |
| I/O | 6 analog/digital |
| Power outputs | 4 x 2 A |
| Dimensions | 186 x 77 x 8 mm |
Published reference information. The confirmed technical documentation for your supplied configuration takes precedence.
DOCUMENTATION
Take a closer look.
Original product documents. Revision and commercial terms must be confirmed with our team.
